Error code C-1353 for Bizhub Press 1250 1250P 1052 Bizhub Pro 951

Code: C-1353
Classification: RU: RU-509 abnormality
Cause:

Error detection signals of FM15, FM16 and FM17 are detected continuously for a specified period of time while the entrance paper fans/4 (FM15), /5 (FM16) and /6 (FM17) are ON.

Measures to take when alert occurs:

         The main body and the option stop immediately.
Estimated abnormal parts:
  • Entrance paper fan /4 (FM15)
  • Entrance paper fan /5 (FM16)
  • Entrance paper fan /6 (FM17)
  • RU control board (RUCB)
Correction:
        Turn OFF/ON the sub power switch (SW2) on the main body when releasing an abnormal condition.
      Note:
  • The message "Please call service" is displayed on the panel.

Solution:

  1. Check the connector connection and the wiring between RUCB and the fan, and repair it if any abnormality.
  2. Rotate the fan or I/O by hand, and repair it if any abnormality. (Wiring diagram: RU-509: 17-L, 18-L).
  3. Replace FM15, FM16 and FM17.
  4. Replace RUCB.
